LS610
Laser Cutting & Engraving System
The LST4896 is large enough to handle big jobs but compact enough to fit into even the smallest shops. The L-Star also the one of most flexible laser systems on the market, with fantastic cutting and engraving features as well as a host of productivity options and everything in between. The L-Star is really a business in itself.
The LST4896 is based on an XY gantry style positioning system. It utilizes dual brushless servo drives in the X axis (long axis) using high precision rack and pinion mechanism on each side. The Y axis uses a single brushless servo motor system driving a high precision belt system. The Y axis positioning system is the result of 2 years of effort to bring the most accurate and fastest system for image engraving on the market the market. In fact we believe the Vytek L-Star is the fastest engraving system in the world.
The LS610 has configurations and options that include custom table options, dual gantries and lasers, as well as material unwind and rewind, to meet the most demanding applications.
MACHINE SPECIFICATIONS
OUTSIDE DIMENSIONS, mm (in), HxWxL
812 x 558 x 660 (22″ x 26″ x 32″)
WEIGHT
WORK AREA
74″ x 122″/1860 mm x 3000 mm
AIR
100-240 VAC 50/60Hz
ELECTRICAL REQUIREMENTS
100-240 VAC 50/60Hz
POWER CONSUMPTION W/O LASER*
≤450W
Table Options
Removable Engraving Deck Option
- Allows for Tile and Marker engraving
- Supports up to 250Lbs
- Easy to remove
Roller Track
- For roll in and roll out or roll through memorial support
- Length of the roller track depends on the machine size
- Insert versus removable track available
Hand Crank Four Post Lift Table
- 2000 lbs. lift capacity
- Maximum stone height 12"
- Roll around cart
Hydraulic Lift Table
- 2000 lbs. lift capacity
- Integrated 10′ roller track
- Foot pedal actuated
Glass Engraving Table
Adjustable vacuum cup leveling fixture maintains a flat surface for high resolution engraving.
Other Options
Fume Extraction Options
- Fume Pumps
- Diaphragm Air Pumps
- Full Width Updraft Manifolds
Extended Height Frame
- Extends frame height for additional clearance under the gantry
- Adds capability to insert thicker stones and casket lids
Optics Options
- 1.5” Focal Length Lens and holder for high resolution engraving
- 4.0” Focal Length Lens and holder for general engraving with surfaces that vary in height
Laser Wattage Options
- 35- or 90-Watt Air Cooled CO2 Laser
- 120, 200 OR 300-Watt Water Cooled CO2 Laser
Urn Engraving Option
- Includes a 5” 3 jaw chuck
- Tailstock with center
- Maximum urn or part length 16″
